Skjermet dobbel strømforsyning.
Stabil i 1 ohm stereo og 2 ohm Brokoblet.
- High-End SQ amplifier
- Shielded dual power supply Skjermet dobbel strømforsyning.
- Discretely constructed MOS-FET amplifier section
- 1-ohm stable stereo / 2-ohms stable in bridged mode
- Smoothly variable BIAS adjustment
- Variable input sensitivity
- Capsulated potentiometers
- Wide range high pass and low pass filter
- Filter range multiplication switch (x10)
- Wide frequency range for high resolution music (10 Hz – 50 kHz)
- Soft start delay
- Operation and protection indicator
- Start-Stop capability (9 -16 Volt)
- Overheat and short circuit protection
- Low distortion Burr-Brown OPA2134PA operation amplifier
- Ground Zero exclusive Mundorf Mcap capacitors
- Solid and high efficient black anodized heatsink
- White illuminated lasered glass logo plate
- Technical data:
- Output Power at 4 Ohm (CEA*): 4 x 125 W
- Output Power at 2 Ohm (CEA*): 4 x 225 W
- Output Power at 1 Ohm (CEA*): 4 x 350 W
- Bridge mode at 4 Ohm (CEA* / 10% THD): 2 x 450 W
- Bridge mode at 2 Ohm (CEA* / 10% THD): 2 x 700 W
- Lowpass: 20 – 400 Hz / 200 – 4000 Hz (switch)
- Highpass: 20 – 400 Hz / 200 – 4000 Hz (switch)
- Bandpass: Yes
- Phaseshift: Yes
- Variable Bias Setting: Yes
- Illumination: Yes
- Dimensions: 22,2 x 6,05 x 42 cm
